Supreme TS4

SUPREME® TS4

SUPREME® TS4

The Supreme TS4 is a targeted design for azimuth and azipull thrusters that have to deal with heavy-duty operations. It provides extra safety for your thruster against water ingress and is custom-made for every application.

Applications

   Azimuth thrusters
  Azipull thrusters



Advantages

   Special thruster design
   Safety measures preventing water ingress
   Condition monitoring
Supreme-TS4
Special-Thruster-Design
Redundant-Lip-Seal
SPECIAL THRUSTER DESIGN
REDUNDANT LIP SEAL

TECHNICAL INFORMATION

Curious about the technical specifications? Download the technical product information for drawings, cross sections and datasheets.

DOWNLOAD PRODUCTSHEET

HOW IT WORKS

The Supreme TS4 protects your thruster against water ingress and oil leakage to the outside environment. The chamber between the two oil-repellent lip seals is filled with oil and the resulting pressure effectively keeps water outside and oil inside the thruster gearbox. The Supreme TS4 is equipped with an additional water-repellent lip seal and is suitable for heavy-duty operation. It may be applied to spray-lubricated and fully oil-filled lower gearboxes and is available for shaft diameters from 140 to 950 millimetres.

MATERIALS

The Supreme TS4 consists of high-quality bronze housing parts and a stainless steel liner. The seal has two water-repellent and two oil-repellent rubber (NBR) lip seals.

CUSTOMISED OPTIONS

Complemented with a broad range of options, the Supreme® seals can be fully customised to your specific sealing need to guarantee your Peace Of Mind.

Overview

   Net cutters
   Wire winders (popular option)
   Cathodic protection (popular option)
   NBR/FKM lip seals
   Hastelloy® C4 springs
   Distance ring
   Dirt barrier (popular option)
   Hard Metal Liner coating (popular option)
   Oil Collector Ring

customised-options

CUSTOMISATION

Are our standard solutions not suitable for your application? Our engineers are more than happy to develop a custom-made sealing product!

TYPE AND DESIGN APPROVAL

The Supreme TS4 seal has been approved by globally recognised classification societies such as the American Bureau of Shipping (ABS), Bureau Veritas (BV), DNV GL and the Indian Register of Shipping. Overview of all available type and design certificates.

Thruster

CONTACT

Do you want more information or specialist advice about the Supreme® TS4 seal? Contact one of our experts!
